Description
Deutsch: Die Abbildung zeigt eine von James Watt entworfene, doppelt wirkende Niederdruckdampfmaschine mit Balancier (Balanciermaschine).

1 und 2 alternierend zugeschaltete Dampfkanäle, A und B Röhrenschieber, C Spritzrohr für Zerstäubung des Kühlwassers im Kondensator (K), D Wasserklappe zwischen Kondensator (K) und Vakuumpumpe (L), E Wasserklappe zwischen Vakuumpumpe (L) und Vorratsbehälter, F Speiserohr für Kesselwasser, G Kühlwassersaugrohr, H Dampfzylinder mit Dampfmantel, uu Steuerkasten Dampfzufuhr/Dampfableitung über 1 bzw. 2, K Abdampf-Kondensator, L Luftpumpe (Vakuumpumpe), M Speisepumpe (mit Windkessel) für Kesselwasser, N Antriebsachse Fliehkraftregler, O-x Kurbel, P Kühlwasserzufluss, S Exzenter, R Antrieb und Übersetzung Fliehkraftregler, T Antriebsriemen Fliehkraftregler, U Schwungrad, W Drosselklappe, Z Doppelt wirkender Kolben.

a-b-c-d-e Balancier, d-d' Gestänge Kühlwasserzuflusspumpe, e-x Pleuelstange, f Kolbenstange, g-h-k, g'-h'-k' Gestänge Fliehkraftregler, k-l-m-n-o-y Gestängeverbindung zwischen Fliehkraftregler und Drosselklappe (W) im Dampfzuleitungsrohr, i Gewichte (Kugeln) Fliehkraftregler, q Dampf Ableitungsrohr, t Kolbenstangengelenk, u Kolbenstange der Vakuumpumpe, v Luftpumpenkolben mit Ventildeckel, z Schieberstange.

c b-b uu r Lemniskoidenlenker,

s aa bb uu s Wattsches Parallelogramm.
English: Six-column beam engine with Murdoch's long-D slide valve
Date

2003-10-29 (original upload date)

Source

4. Auflage des Werkes de:Meyers Konversations-Lexikon von 1885-1890. Original can be found at [1]

Author

Original uploader was Ulrich.fuchs

Permission
(Reusing this file)

This image is in the public domain due to its age; This image is in the public domain.
(Original text : Gemeinfrei)

Licensing

Public domain This image (or other media file) is in the public domain because its copyright has expired.

This applies to Australia, the European Union and those countries with a copyright term of life of the author plus 70 years.


Dialog-warning.svg You must also include a United States public domain tag to indicate why this work is in the public domain in the United States. Note that a few countries have copyright terms longer than 70 years: Mexico has 100 years, Colombia has 80 years, and Guatemala and Samoa have 75 years, Soviet Union has 74 years for some authors. This image may not be in the public domain in these countries, which moreover do not implement the rule of the shorter term. Côte d'Ivoire has a general copyright term of 99 years and Honduras has 75 years, but they do implement the rule of the shorter term.


This file has been identified as being free of known restrictions under copyright law, including all related and neighboring rights.

Original upload log

The original description page is/was here. All following user names refer to de.wikipedia.

  • 2003-10-29 20:33 Ulrich.fuchs 783×714×8 (133399 bytes) Watt'sche Niederdruck-Dampfmaschine (groß) aus dem alten Meyers-Lexikon
Photo's description:
Six-column beam engine with Murdoch's long-D slide valve
Licensing:
Public Domain
